Ultra-wide adjustable edge gap: 0.1 – 4.0 mm — the broadest range combining ultra-precision fine-mist removal at 0.1 mm with heavy-duty air curtain capability at 4.0 mm
Three inlet configurations in one model: End (both sides), Side (M6 thread), Bottom — maximum layout adaptability for any machine orientation
Four compatible inlet diameters: Φ32 / Φ38 / Φ45 / Φ51 — connects directly to most standard compressed air supply lines without adapters
Factory-customizable length: 50 – 4000 mm — from compact 50 mm spot-drying fixtures to 4-metre wide-format industrial drying systems, produced and calibrated in-house
High-temp silicone gasket seals (≤250°C) and full OEM/ODM support — every unit factory-built and verified to your exact specification
Product Key Selling Points
• Ultra-wide adjustable edge gap: 0.1 – 4.0 mm — the broadest range combining ultra-precision fine-mist removal at 0.1 mm with heavy-duty air curtain capability at 4.0 mm
• Three inlet configurations in one model: End (both sides), Side (M6 thread), Bottom — maximum layout adaptability for any machine orientation
• Four compatible inlet diameters: Φ32 / Φ38 / Φ45 / Φ51 — connects directly to most standard compressed air supply lines without adapters
• Factory-customizable length: 50 – 4000 mm — from compact 50 mm spot-drying fixtures to 4-metre wide-format industrial drying systems, produced and calibrated in-house
• High-temp silicone gasket seals (≤250°C) and full OEM/ODM support — every unit factory-built and verified to your exact specification
Product Structure & Working Principle
• Compact 50W × 100H mm aluminum alloy extrusion body — slim enough for confined spaces, with sufficient internal volume for stable pressure distribution
• Three inlet options — end (both sides simultaneously for balanced long-run pressure), side (M6 thread for lateral pipework), and bottom (for flush or overhead mounting) — cover all standard installation geometries
• Internal plenum chamber evenly distributes compressed air pressure from whichever inlet is used, across the full blade length from 50 mm up to 4000 mm
• Tapered acceleration duct converts equalized plenum pressure into a concentrated, uniform high-velocity laminar air sheet at the precision outlet slot
• Outlet gap continuously adjustable from 0.1 mm to 4.0 mm via edge screws — widest adjustment range in the aluminum alloy lineup, no disassembly required
• High-temp silicone gasket seals at both ends (≤250°C) maintain airtight blade terminations across a wide range of process temperatures
Application Scenarios
The A-G's combination of the widest gap range, most inlet options, and longest customizable length makes it the most versatile single model in the aluminum alloy air knife lineup:
• PCB Cleaning Lines — adjustable gap and multiple inlet options allow the A-G to be retrofitted into virtually any existing wash-line frame configuration
• Surface Drying — Bottles, Parts & Sheet Materials — 0.1–4.0 mm range adapts to different product sizes, surface types, and conveyor speeds on the same station
• Dust Removal on Panels, Glass & Optical Surfaces — 0.1 mm minimum gap enables controlled, non-damaging particle displacement on sensitive substrates
• Wide-Format Drying Lines (up to 4000 mm) — glass, metal sheet, textile, and film production lines covered in a single continuous knife without mid-run joints
• Multi-Orientation Installations — end, side, or bottom inlet selection adapts the knife to overhead, lateral, upward-blowing, or downward-blowing mounting requirements
• Heated Process Equipment — silicone gasket seals rated to ≤250°C permit integration into drying ovens, heat tunnels, and thermal conveyor systems
Technical Parameters
Parameter | Specification |
Model | A-G Air Knife (A-G adjustable air knife) |
Cross-Section Size | 50W × 100H mm |
Main Material | Aluminium Alloy |
Air Inlet Position | End (Both Sides), Side (M6), Bottom |
Air Inlet Size | Φ32 / Φ38 / Φ45 / Φ51 |
Inlet Thread (Side) | M6 |
Air Knife Edge Size | 0.1 – 4.0 mm (Adjustable) |
Customizable Length | 50 – 4000 mm |
End Sealing | High-Temp Silicone Gasket Seal (≤250°C) |
OEM / ODM | Supported |
Factory Capability · Customization · Service
• Full in-house CNC machining — 50×100mm blade body, internal plenum, all three inlet configurations (end / side M6 / bottom), and outlet slot produced and verified on-site
• Custom lengths from 50 mm to 4000 mm manufactured to order — the longest available range across the aluminum alloy lineup — with dimensional and pressure verification before shipment
• Inlet position (end / side / bottom), pipe diameter (Φ32–Φ51), air gap setting (0.1–4.0 mm), and surface finish all configurable per customer specification
• OEM and ODM manufacturing supported — accept engineering drawings, physical samples, or written application requirement descriptions
• High-temp silicone gasket seals (≤250°C) fitted as standard on every unit — no surcharge or extended lead time for heated-process variants
• Pre-shipment quality protocol: pressure integrity test, edge-gap calibration to specified tolerance, inlet port thread check, and full dimensional inspection report
Competitive Advantage
Comparison Item | QXY A-G Air Knife | Standard Air Knife |
Air Gap Adjustability | Adjustable 0.1–4.0 mm ✓ | Fixed, not adjustable ✗ |
Inlet Positions | End (dual) / Side (M6) / Bottom | End only |
Inlet Pipe Options | Φ32 / Φ38 / Φ45 / Φ51 | Single size typical |
Min. Edge Gap | 0.1 mm — ultra-precision | 0.5 mm or fixed |
Customizable Length | 50–4000 mm from factory | Standard fixed sizes only |
High-Temp Sealing | Silicone gasket ≤250°C ✓ | Standard rubber seal ✗ |
Customization | Length, gap, inlet, finish | No customization |
About Us & Custom Inquiry
Shenzhen Qixingyuan Machinery Equipment Co., Ltd.
We are a specialized manufacturer of industrial air knife systems, with a full product line covering aluminum alloy, stainless steel, and PVC air knives alongside blowers, mounting hardware, and complete drying system accessories. Our production facility is equipped with precision CNC machining centers and operates under strict in-process quality controls — ensuring that every air knife, from its internal plenum geometry and outlet slot calibration through to inlet port threading and end seal installation, is manufactured and verified against specification before leaving the factory.
We have extensive experience supporting OEM and ODM clients across the electronics, automotive, food and beverage, pharmaceutical, and general manufacturing industries worldwide. Whether the requirement is a direct-replacement single knife or a fully engineered multi-knife production-line drying system, our engineering team works from your drawings, samples, or application descriptions to deliver a solution that integrates and performs exactly as required.
Request a Custom Quote
We support customized air knife length, air gap, and airflow design according to your equipment requirements.
